Energy Saving 415V 3 Phase Electric Motor With JIS Certificate
Place of Origin | China |
---|---|
Brand Name | Wanan |
Certification | CE, ISO9001, CCC, RoHS, Reach |
Model Number | YXEJ |
Minimum Order Quantity | Negotiable |
Price | USD, RMB, EURO |
Packaging Details | Carton/Wooden Case/Pallet |
Delivery Time | 10 days to 30 days |
Payment Terms | T/T, L/C, Western Union, MoneyGram |
Supply Ability | 2000PCS per month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xName | Energy Saving 415V 3 Phase Electric Motor With JIS Certificate | Phase | 3 Phase |
---|---|---|---|
Feature | Energy Saving | Power | Customized |
Certificate | JIS | Housing | Cast Iron, Aluminum, Stainless Steel |
Protection Degree | IP55/56/65 | Warranty | 12 Months |
Highlight | JIS 3 Phase Electric Motor,415V 3 Phase Electric Motor,Customized Cast Iron Three Phase Motors |
Energy Saving 415V 3 Phase Electric Motor with JIS Certificate
1. Description
Introducing the innovative "Energy Saving 415V 3 Phase Electric Motor with JIS Certificate" – a game-changing motor designed to optimize energy efficiency and meet international quality standards. This motor is a testament to technological advancements in the pursuit of sustainable operations.
With a focus on energy conservation, this motor incorporates advanced technologies that minimize power consumption without compromising performance. By reducing energy waste, it not only lowers operational costs but also contributes to a greener, more sustainable industrial environment.
Operating on a 415V 3-phase power supply, this motor delivers reliable and efficient performance across a wide range of industrial applications. Its high voltage rating ensures stable power transmission, enabling seamless integration into existing systems.
Accompanied by the prestigious JIS certificate, this motor meets the stringent quality standards set by the Japanese Industrial Standards organization. This certification guarantees compliance with industry regulations, ensuring superior performance, durability, and safety.
In addition to its energy-saving features, this motor boasts a robust design that enhances its longevity and reliability. High-quality components and meticulous engineering enable it to withstand harsh operating conditions, including high temperatures and heavy loads.
The "Energy Saving 415V 3 Phase Electric Motor with JIS Certificate" is an ideal choice for industries seeking sustainable solutions without compromising performance. From manufacturing plants to commercial facilities, this motor offers exceptional energy efficiency, reduced carbon footprint, and reliable operation.
Embrace the future of energy-saving technologies with this cutting-edge motor. Experience the benefits of reduced energy consumption, improved sustainability, and compliance with international quality standards. Stay ahead of the competition and contribute to a greener tomorrow with this innovative motor.
2. Specifications
Model NO. |
YXEJ |
Starting Mode | Direct on-line Starting |
Certification | ISO9001, CCC, Ce, RoHS, Reach |
Brand | Wannan Motor |
Frame | 80-315mm |
Output | 0.18-220kw |
Efficiency | IE2 |
Poles | 2, 4, 6, 8, 10 |
Duty | S1 |
Insulation | F |
Cooling |
IC411-Tefc |
Protection Degree |
IP55 (Motor) & IP23 (Brake) |
Voltage | 380V, or Customized |
Frequency | 50Hz, 60Hz |
Terminal | Top, Right Side, Left Side |
Housing | Cast Iron, Aluminum, Stainless Steel |
Service Factor | 1.0 |
Mounting Type |
B3, B5, B35 |
Ambient Temp. | 40°c, 1000 M. a.S.L |
Transport Package | Carton/Wooden Case/Pallet |
Trademark | WNM |
Origin | China |
HS Code | 8501520000 |
Production Capacity | 2000PCS/Month |
3. Features
Electromagnetic brake, fast braking, energy saving, simple structure, exact position.
Optional Features:
Electrical:
Insulation Class:H
Thermal Protection: PTC Thermistor, Thermostat or PT100
Mechanical:
Others mountings
Sealing:Lip seal, Oil seal
Space Heater
Drain Hole
4. Applications
Widely used for driving machine tools, printing machinery, forging press, transport machinery, packing machinery, food machinery, construction machinery, and woodworking machinery where quick stop, accurate braking, reciprocated operation are demanded.
5. FAQ
Q: Are you a factory or a trading company?
A:We are a factory with 65 years (Since year 1958) manufacturing experience.
